Laird Connectivity is a leading provider of wireless connectivity solutions that offers an extensive portfolio of innovative wireless modules, System-on-modules (SOMs), antennas, and internet of things (IoT) devices. Their BL5340PA series is a comprehensive line of robust, power-amplified Bluetooth Low Energy (LE) modules that utilize the nRF5340 SoC from Nordic Semiconductor to provide the highest performance at the lowest power budget. The BL5340PA series incorporates Nordic’s nRF21540 PA/LNA for increased TX Power applications. Laird Connectivity’s BL5340PA series offers compelling solutions that deliver high-performance, low-power, and secure wireless connectivity for a broad range of applications, including next-generation Bluetooth LE Audio, industrial automation, smart home devices, and more.

Designed to provide next-generation Bluetooth audio streaming, BL5340PA modules offer Bluetooth 5.2 LE support including Isochronous Channels and LE Audio. Additionally, their integrated dual-core Arm® Cortex M33 microcontrollers enable low-power core operation that is dedicated to wireless connectivity while a second, higher-performance core targets the end application. This further enhances the product's multi-protocol capabilities, which include Bluetooth LE, 802.15.4 (Thread / Zigbee), and NFC. The BL5340PA is also equipped with an ARM CryptoCell312, which enables secure key storage, trusted execution, and root-of-trust security features.

The BL5340PA series provides access to all nRF5340 hardware features and capabilities, such as USB access, transmit power of up to +18.5 dBm, 3.0V to 3.6V supply considerations, and an industrial operating range of -40 to 105°C. Laird Connectivity simplifies your next multi-protocol wireless design with multiple regulatory certifications that reduce development risk and enable faster time-to-market.

BL5430PA Series Modules

BL5430PA Series Development Kits

Key Features:

• Based on Nordic Semiconductor nRF5340 SoC and nRF21540 Front End Module (PA/LNA)
• Bluetooth v5.2 – Single mode (Bluetooth Low Energy)
• NFC
• IEEE 802.15.4-2006 (Thread or Zigbee) radio support
• External or integrated antennas
• Programmable Tx power +18.5dBm to -20 dBm
• Note: See section 6.2.4 for actual radio regulator RF TX power limit allowed for each regulatory region.
• Rx sensitivity -103 dBm (1 Mbps), - 108.5 dBm (125 kbps)
• Ultra-low power consumption
• System ON Idle – 3.1 uA typical
• UART, GPIO, ADC, PWM, timers, I2C, QSPI, SPI, I2S, PDM, and USB interfaces
• FCC, ISED, and RCM certified
• Full Bluetooth Declaration ID
• Other regulatory certifications on request
• No external components required
• Industrial temperature range (-40° C to +105° C)

Conclusion

The BL5340PA series offers a powerful solution for OEM customers seeking the highest MCU performance and longest range for their wireless connectivity requirements. By incorporating the Nordic nRF5340 SoC/ nRF21540 FEM, the series significantly enhances wireless range, connection, and multi-protocol capabilities. Whether you are developing next-generation Bluetooth LE Audio devices, industrial automation systems, or smart home devices, the BL5340PA series provides a powerful and flexible platform to meet your wireless connectivity needs.
